Enforcer™ | Custom Chassis | Pierce Mfg

The legacy grows.

ENFORCER BROCHURE

Overview

Proven reliability returns. The Pierce Enforcer chassis is more capable than ever. With TAK-4^® independent front suspension, your choice of three powerful engines and Pierce's exclusive Command Zone™ multiplexed electrical system, the Enforcer performs like never before.

Plus you can take advantage of significant improvements in visibility, space, ergonomics and serviceability.

Enforcer 360° Interior Tour

Enforcer Custom Fire Truck Chassis Interior

Visibility & Space

Exceptional visibility is achieved through a large, bonded, single-piece, wrap-around windshield.

The smaller engine tunnel is lower & more contoured for increased occupant space, particularly up front for the driver & officer.

The forward roof design offers a cathedral ceiling feel with increased frontal visibility & more configurable space.

Ergonomics

Exterior door handles are functionally designed for a firefighter's gloved hand.

The steps are lower to the ground & offset to function like a stair step, making it easier for firefighters to enter & exit the cab.

The console & metal overhead switch panel are ergonomically designed for maximum convenience & comfort, keeping all of the gauges & switches within easy reach of the driver.

Serviceablity

Easy access to the defroster & wiper motors through removable officer-side panels.

Power distribution relocation provides more interior space & fewer harnesses in the frame & up through the cab for easier servicing.

Built-in wire raceways throughout the cab reduce the chance of wire chafing & make it easier to service or add cab harnesses & wiring.

Maneuverability

Maximum 50-degree cramp angle & 15-degree angle of approach for improved maneuverability in those tight areas & challenging situations.

Specifications

Engine Horsepower

370 - 600 hp

Cab Dimensions

Length 60", 70" or 84" / Width 96"

Cab Roof Style

Flat or raised (10" or 24")

Design

Cab Dimensions	Length 60", 70" or 84" / Width 96"	Cab Roof Style	Flat or raised (10" or 24")
Doors	Barrier or full height	Electrical System	Hard Wired or Command Zone™
Frame Rail	13-3/8" standard; 10-1/4" optional	Front Axle Suspension	Leaf or TAK-4®
Frontal Air Bags	Default	Rear Axle Suspension	Leaf, rubber, air, TAK-4® or TAK-4 T3™; single or tandem
Seating Capacity	8	Side Roll Protection	Default

Performance

Alternator	270 - 430 amp	Cramp Angle (maximum)	50°
Engine	Cummins X10, X15 or PACCAR MX	Engine Horsepower	370 - 600 hp
Front GAWR (maximum)	24,000 lb	Rear GAWR (maximum)	60,000 lb
Transmission	Allison 3000 EVS, 4000 EVS or 4500 EVS

Proprietary Options

Aerial	Snozzle®	Electrical	Command Zone™
Pump	PUC™	Suspension	TAK-4® Independent Front Suspension TAK-4® Independent Rear Suspension

Exterior Gallery

Cab tilt

An increased cab tilt angle improves access to the chassis components under the cab.

Oversized door handles

Exterior door handles are functionally designed for a firefighter's gloved hand.

Large front door

Side visibility is improved by a slightly larger front door and a narrower A-pillar.

Forward roof design

The forward roof design offers a cathedral ceiling feel with increased frontal visibility and more configurable space.

Low, offset cab steps

The steps are lower to the ground and offset to function like a stair step, making it easier for firefighters to enter and exit the cab.

Single front windshield

Exceptional visibility is achieved through a large, bonded, single-piece, wrap-around windshield.

Interior Gallery
