Ascendant® 102' Heavy-Duty Tiller Aerial Ladder

102' Tiller Tractor Drawn Aerial

Maximum maneuverability and a shorter tiller length.



Overview



The Ascendant 102' Heavy-Duty Tiller Aerial Ladder provides the same performance criteria and innovative design as our 107' with a shortened aerial and trailer to provide a short tiller configuration with maximized maneuverability.

Specifications

Flow Capacity

1,000 gpm with ladder pipe only

Payload Capacity

750 lb dry / 500 lb wet

Ladder Reach

102' Vertical / 95' Horizontal

Design

Custom ChassisEnforcer™, Velocity® Rear AxleSingle or tandem
Stabilizer Spread17' Stabilizers1 set of H-style
Structural Ladder Warranty 20-yr

Performance

Flow Capacity1,000 gpm with ladder pipe only Hosebed Capacity1,000' of 5"
Ladder ComplementUp to 250' (depending on configuration) Ladder Reach102' Vertical / 95' Horizontal
Operating Range-10° to 77° Payload Capacity750 lb dry / 500 lb wet
Pump RangeWaterous, Hale, Darley Midship, PTO TankUp to 300 gallons
Wind or Ice RatingsUp to 35 mph winds and 1/4" of ice

Proprietary Options

Electrical Command Zone™
 Foam Systems HERCULES™ CAFS
Husky™ 12
Husky™ 3
Pump PUC™
 Suspension TAK-4® Independent Front Suspension

Aerial Ladder

  • Heavy-duty high strength steel
  • Innovative gusset design
  • Clean tip design
  • Below grade operation (-10⁰)
  • Multiplexed
  • 100 lb additional equipment allowance at tip
  • Smoother and quicker deployment speeds
102-Aerial-Tiller-Ladder-1
